Phantom Power:
48V DC (CH1)
Input Channels:
1 Mono MIC/LINE (XLR ¼” combo), 2 Stereo LINE (1/4”), 1 Stereo 1/8”, 1 Bluetooth
Output Channels:
1 Stereo MAIN OUT (XLR), 1 Stereo REC OUT (1/8”)
Headphone Output:
1 Stereo (1/4”)
80Hz High-Pass Filter:
1 (CH1)
Guitar Hi-Z Input:
1 (CH 2|3)
EQ HIGH:
±12dB@ 10 kHz (shelving)
EQ LOW:
±12dB@ 100Hz (shelving)
LED Meters:
4-Segment (CLIP, +5, 0, -10)
Dimensions WxDxH:
6.4” x 5.5” x 2”
Phantom Power:
48V DC (CH1)
Input Channels:
1 Mono MIC/LINE (XLR ¼” combo), 2 Stereo LINE (1/4”), 1 Stereo 1/8”, 1 Bluetooth
Output Channels:
1 Stereo MAIN OUT (XLR), 1 Stereo REC OUT (1/8”)
Headphone Output:
1 Stereo (1/4”)
80Hz High-Pass Filter:
1 (CH1)
Guitar Hi-Z Input:
1 (CH 2|3)
EQ HIGH:
±12dB@ 10 kHz (shelving)
EQ LOW:
±12dB@ 100Hz (shelving)
LED Meters:
4-Segment (CLIP, +5, 0, -10)
Dimensions WxDxH:
6.4” x 5.5” x 2”
